DH-2.4
DH-2.4
DH-2.4
DH-2.4
DH-2.4
DH-2.4
DH-2.4
DH-2.4

DH-2.4

TCPUMPER

TCPumper DH-2.4 is a pump station developed for pipeline flame machine, which can automatically refuel 4 pipeline flame machines over a long distance. The whole machine adopts 304 stainless steel housing, LCD display, equipped with pressure and fuel level monitoring, switchable refueling and pressure, no fuel prompt, tilt protection and other functions. It is easy to operate, safe and convenient.

INQUIRE NOW NEXT PRODUCT
DH-2.4



Features

30 L fuel tank;

Support 4 flame machines;

Remote fuel and pressure supply;

Configured with pressure and fuel level monitoring;

Switchable refueling and pressure;

No fuel prompt and tilt protection;

LCD display control and DMX control;

304 stainless steel housing.




Specifications
AC POWER

Input Voltage & Rate: 220-240 V, 50/60 Hz

Current Limiter Type: Breaker

Current Limiter Specifications: 10 A, 250 V

Total Power Consumption: 2,500 W

Power Input Connector: Lockable PowerCon

CAPACITY

Fluid Tank Capacity : 30 L

OUTPUT

Pump Output: Appr. 15 L/min

Max. Supported Flame heads: 4 pcs

CONTROL

Working Mode：Fueling /Pressurize

On-device Manual Control : LCD control board

Wireless Control: ×

Control Protocol: DMX-512

DMX Channel Range: 6

Data Connectors: 3- and 5-pin XLR

CONSUMABLE

Consumable: Isopropyl alcohol, Bio-Ethanol, Isopar-G

WEIGHT & DIMENSIONS

Net Weight: 50 kg

Gross Weight: 74 kg

Machine Dimensions: 700 × 460 × 425 mm

Flight case Dimensions: 835 × 520 × 583 mm

Packing Dimensions: 930 × 615 × 565 mm
