This model is with high cost performance!Convenient and safe for use.
Stable performance and fog output;
Equipped with electronic temperature control system, high-accuracy temperature control PCB and new professional atomizer;
Easy set timing and quantitative work;
3-pin DMX512 input/output socket;
No-fluid protection for safety use;
Built-in LCD control and wireless control. Remote controller is convenient for group use, several units used together can be selectable control;
Please use DJPOWER professional fog fluid DJV-001 or D-01.
Input Voltage & Rate: 220-240 V, 50/60 Hz
Current Limiter Type: Breaker
Current Limiter Specifications: 8 A, 250 V
Total Power Consumption: 1,350 W
Operating Current: 5.9 A
Power Input Connector: Hard-wired
Heat Up Time: Appr. 5.0 min
Heater Type: Aluminum Heater Block
Fluid Tank Capacity : 3 L
Adjustable Volume: √
Volume Adjustment Level/Range: 1-100%
Max Output Volume: Appr. 30,000 cuft/min
Max Output Distance : Appr. 6 m
Fluid Consumption @ full volume : Appr. 149.3 mL/min
Maximum Continuous Duration @ full volume: Appr. 15 sec
Continuous Output : ×
Max Continuous Output Level: 100%
Fully-loaded Cumulative Output Duration @ full volume: Appr. 20 min
Physical Thermostat: √
Electronic Thermo-Control: √
No-Fluid Protection: √
Instant-Stop: ×
On-device Manual Control : LCD control board
Wireless Control: W-2 / RF 315MHz / External receiver
Control Protocol: DMX-512
DMX Channel Range: 1
Data Connectors: 3-pin XLR
Power Cord: √
Wireless Controller Model: W-2 / RF 315MHz / Transmitter & Receiver
Consumable: DJV-001 or D-01 or D-03 Fog Fluid
Net Weight: 9.4 kg / 20.7 lb.
Gross Weight: 10.5 kg / 23.1 lb.
Machine Dimensions: 478 × 346 × 233 mm / 18.8 × 13.6 × 9.2 in.
Packing Dimensions: 525 × 355 × 290 mm / 20.7 × 14 × 11.4 in.
